Zirconia ceramic guide wheel

  • Zirconia ceramic guide wheel
  • Zirconia ceramic guide wheel
  • Zirconia ceramic guide wheel
  • Zirconia ceramic guide wheel

Zirconia ceramic guide wheel

    Packaging: Export carton pallet
    Brand: HONY
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: Enough
    Certificate: SGS RoHS Reach ISO9001
    Port: Shenzhen,Guangzhou,HongKong

Basic Info

Model No.: HONYCERAMIC-Zirconia Wheels

Product Description

HONY®Zirconia guide wheels Zirconia Ceramic Machinery Parts Custom-made ZrO2 Zirconia Ceramic Guide Wheel

Wear Resistance,Corrosion Resistance,High Temperature Resistance,Insulation,Zirconia ceramics is a new type of high-tech ceramics. Among all engineering ceramics, zirconia ceramics have the highest strength and toughness at room temperature. The thermal conductivity of zirconia is the lowest among common ceramic materials, and the coefficient of thermal expansion is close to that of metals. Therefore, zirconia ceramics are suitable as structural ceramic materials.

Ceramic Zirconia Ceramic before zirconia, ceramics were considered unsuitable for scissors or knife applications.

Zirconia has excellent surface smoothness and can also be used for pump parts

Zirconia Ceramic Part

high toughness,

high bending strength

high wear resistance

excellent thermal insulation properties

the coefficient of thermal expansion is close to steel

Zirconia ceramic are widely used in the field of structural ceramics.

Mainly include: TTZP grinding ball, dispersion and grinding price, nozzle, ball valve ball seat, zirconia mold, micro fan shaft, optical fiber pin, optical fiber sleeve, wire drawing die and cutting tool, wear-resistant tool and other room temperature mills Parts etc.

HONYCERAMIC-Zirconia Properties Data Sheet
Property Item Data Unit



Color Ivory -
Density 6.02 g/cm3
Bending Strength 800 MPa
Compressive strength 3000 MPa
Elastic Modulus 200 GPa
Weber Coefficient 15 m
Vickers Hardness 1200 HV 0.5
Fracture Toughness 8 MPa m1/2
Thermal Characteristics Coefficient of Line Thermal Expansion 10 10-6K-1
Thermal Conductivity 3 W/mK
Thermal Shock Resistance(Put in water) 300 T ℃
Max Working Temperature 1000
Electrical Characteristics Volume Resistance at 20℃ >1013 Ωcm

Dielectric Strength 11x106 V/m

Dielectric Constant 33 εr

One MHZ Dielectric Loss Angle at 20℃ 0.0016 tanδ
Chemical Characteristics
Nitric Acid (60%) 90°C
WT Loss mg/cm^2/day

Sulphuric Acid (95%) 95°C

Caustic Soda (30%) 80°C

Precision Zirconia Machining Ceramics Machining Precision Service :

(1) Shaft: roundness 0.002 mm, concentricity 0.002mm, smoothness Ra0.1;

(2) Hole: The minimum processing hole diameter is 0.2 mm, and the depth can reach 6 mm (depending on the material);

(3) Groove (slit): The smallest 0.1mm narrow groove and grooves of various shapes can be processed;

(4) Plane: minimum processable thickness 0.1mm thin slice, parallelism 0.001mm, measurement tolerance 0.001mm, smoothness Ra0.1;

(5) Thread: the smallest can be machined M2 internal thread, the accuracy is GB-7h, the external thread size is not limited, the accuracy is GB-6g






Q: Are you a factory or a trading company

A: We are a professional manufacturer of ceramic parts. we are factory.

Q:Do you only supply standard parts or can customized parts according to our drawing?

A: All parts can be customized according to you drawings and will meeting your requirements perfectly.

Q:Can the price be negotiated

A: Of course, we will consider discounts for large-volume orders.

Q:Can you guarantee the product?

A: Yes, we promise to provide quality assurance for all products, inspect according to your drawings and issue an inspection report. If you are not satisfied with our product quality or service, please feel free to give us feedback.

Q:Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q:Will my drawing be divulged if you benefit?

A:No,we pay attention to protect our customer's privacy of drawings , signing NDA is also accepted if need .

Q:What is the delivery day ?

A:It will be 7-11 days work days .
